Product Description

Name: LED Street Light

Model No: NK-SLW6-180W

Certificated by: ICON ICON

LED by:  BRIDGEX philips

Powered by: mwOR High Efficiency Driver

Share this product:

chat button

Product Details

Specifications
Model No.  NK-SLW6-180W Lamp Power  180 W
LED luminous efficiency 120~140 lm/W Equivalent 500 W  high pressure sodium lamp
Lamp Rated luminous efficiency 110 lm/W Lamp Total Flux(Tj=60℃,Ta=25℃) 19800 lm
Input Voltage  AC100–277V Mounting height(m)  12–15 m
Lamp Efficiency   >93% Total Harmonic Distortion (THD)   <15%
Power Factor (PF)   >0.97 Color Rendering Index (CRI)   >80 Ra
Beam Angle Horizontal Axis: 120°                           Vertical Axis: 60° Color Temperature   3000k—7000K
Waterproof  IP65 Warranty 3–5 Years
Light Distribution Curve   Rectangular Beam Lifespan >50,000hrs
Working Temperature   -30℃ ~ +50℃ Lamp Body and Lampshade Material   Aluminum Alloy and PMMA
Lamp Size  796 x 318 x 125mm Net weight 10.5 kg
Application place Highways, freight terminals, squares, golf courses, parks, car parks, industrial parks, leisure and tourism scenic spots.
Notes  Dimmable or non dimmable , Body sensor dimming, sensor switch, Illuminated sensor switch , Connect the solar control system, 90 degrees adjustable bracket .
Parameter
Application

led-street-light-2

led street light
